24-Port Gigabit Industrial Managed Switch with 16 1000BASE-T ports, 4 SFP ports and 4 10G SFP+ ports
DIS-310G-24X
- 16 1000BASE-T ports, 4 SFP ports and 4 SFP+ ports
- Advanced Layer 3 features
- Robust and High-Redundancy Design
- DIN Rail mountable
- Fanless, passive cooling design
- High EMC endurance
- Dual power input for redundant power supplies
- 6kV surge protection on copper ports
- CLI and Web GUI management
The DIS-310G-24X Gigabit Industrial Managed Layer 3 Switch is equipped with 16 10/100/1000BASE-T ports, 4 Gigabit SFP ports and 4 10GB SFP+ ports. The DIS-310G-24X switch features a robust design making them ideal for deployment in industrial and outdoor surveillance settings, capable of withstanding the harshest environments. The DIS-310G-24X furthermore integrates advanced management and security functions to provide a complete solution.
.png)
Features
 |
Easy Management
Easy to manage with user friendly Web-based management and industry-standard CLI.
|
 |
Gigabit and 10 Gigabit Connectivity
Designed with 16 x Gigabit ports, 4 x SFP and 4 x SFP+ slots to suit a range of network layouts.
|
 |
Compact Size
Small but mighty. To make the most of cabinet space, it measures: 100 x 140 x 170 mm.
|
 |
Fast Deployment
For instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting.
|
|
|
|
|
|
|
 |
High Availability
Fast Ring failover recovery time of < 50ms.
|
 |
Withstands Extreme Temperatures
Operates in harsh environments with temperatures from -40°C to +75°C.
|
 |
Strong Build
The tough housing has been created to keep your network protected and reliably rugged.
|
 |
Fanless Design
With no moving parts inside to reduce downtime and maintenance call outs.
|
|
|
|
|
|
|
Durable and Reliable Design
The DIS-310G-24X switch is housed in a highly resistant metal casing to protect the switches from harsh environments. The high electromagnetic compatibility (EMC) protects the switch from unwanted electromagnetic interference. Meanwhile, the fanless design extends the life of DIS-310G-24X while also being able to operate in a wider temperature range of up to 75 °C. For increased flexibility, the DIS-310G-24X can also be mounted on a DIN rail, wall mounted, or be installed in an equipment rack.
High Redundancy and Reliability
The DIS-310G-24X switches support Fast Ring Failover recovery for ring topologies that ensures minimal downtime and avoids any loss of data in mission-critical deployment settings. Meanwhile, the dual power input allows for a redundant power supply to make sure the network continues to operate in the event of a primary power supply failure.
Easy Troubleshooting
The DIS-310G-24X features loopback detection and cable diagnostics to help network administrators find and solve network problems quickly and easily. Loopback detection is used to detect loops created by a specific port and automatically shuts down the affected port. Cable diagnostics helps network administrators quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.
| 1000BASE-T Ports : | 16 |
| SFP Ports : | 4 |
| SFP+ ports : | 4 |
| PoE Type Required : | None |
| Switching Capacity : | 120 Gbps |
| MAC Address Table Size : | 16K |
| Metal Housing : | Yes |
| DIN Rail Mountable : | Yes |
| Power Input : | 48 to 60 DC terminal block dual input |
| Fans : | Fanless |
| Operating Temperature : | From -40° to 75°C |
| Surge Protection : | 6 kV Surge Protection |
| Management Options : | Managed |
| Switch Series : | DIS Industrial Series |
