32-Port 10 Gigabit Layer 3 Stackable Managed Switch with 28 10Gb SFP+ Ports and 4 10/25Gb SFP28 Ports
DXS-3410-32SY
- 10 Gigabit Layer 3 Stackable Switch
- 28 10Gb SFP+ ports
- Four 25Gb SFP28 uplink ports
- Stackable up to 9 units (physical), 32 units (virtual)
- Supports long-distance stacking over fibre
- 200 Gbps per device stacking bandwidth
- Lossless Ethernet via Data Center Bridging (DCB)
- Redundant power supply support
- Industry standard CLI
- Easy management via a user-friendly Web GUI
- Centralised management through cloud-based Nuclias Unity and on-premises software Nuclias Hyper
Adaptable, Bottleneck-Free 10G Business Connectivity
The DXS-3410 Series is a highly versatile Layer 3 stackable switch. Including powerful L2 & L3 features, it is highly pliant, capable of accommodating different network deployments.
The DXS-3410 Series switches are equipped with multi-Gigabit Ethernet and SFP+ network connection options and include models with multi-Gigabit Ethernet and SFP28 network connection capabilities. Each model boasts 10G fibre ports and four 10/25G SFP28 ports to provide versatility and speed.
Highly Available. Highly Flexible.
The DXS-3410 Series allows multiple switches to be combined to form a single physical or virtual stack. This increases redundancy over multiple physical units, simplifies management, and provides a single IP address to manage all members in the stack. Up to 9 switches can be combined using DACs/Fibre to make up to 252 10Gb Ethernet ports available, allowing switching capacity to be increased with demand.
Slash Your Network Downtime
The DXS-3410 Series gives enterprises and organisations a highly reliable network, allowing for maximum business continuity. It has built-in G.8032 Ethernet Ring Protection Switching (ERPS) to help minimise recovery times to 50 ms.
Along with a host of essential network reliability features, all switches in the series support an external redundant power supply to ensure your operations continue unimpeded.
Comprehensive Security
The DXS-3410 Series provides users with the latest security features such as Multi-layer and Packet Content Access Control Lists (ACL), Storm Control, and IP-MAC-Port Binding (IMPB) with DHCP Snooping.
Other advanced features like DHCP Snooping let the switches automatically learn and save IP/MAC pairs to the IMPB white list.
Easy Access Control Policies
The DXS-3410 Series supports authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC) for strict access control and easy deployment. After authentication, individual policies such as VLAN membership, QoS policies, and ACL rules can be assigned to each host.
Versatile Traffic Management
The DXS-3410 Series implements a rich set of multi-layer QoS/CoS features to prioritise critical network services such as VoIP, video conferences, IPTV, and IP surveillance. With robust features including Traffic Shaping, L2 Multicast, Host-based IGMP/MLD Snooping and ISM VLAN, administrators get a whole new way to manage their traffic that fits their needs.
Flexible Network Management
Manage your network your way. D-Link DXS-3410 switches can be managed individually through their built-in web interface, or centrally using Nuclias Unity cloud management or Nuclias Hyper on-premises management software, giving you the flexibility to choose the approach that best suits your network.
| Warranty : | Limited Lifetime |
| Switching Capacity : | 760 Gbps |
| QoS : | Yes |
| Spanning Tree Protocol : | Yes |
| Link Aggregation : | Yes |
| VLAN : | 4K Groups |
| Jumbo Frame : | 10000 bytes |
| DHCP Server Screening : | Yes |
| SNMP : | Yes |
| Cable Diagnostics : | Yes |
| Voice VLAN : | Yes |
| Energy Saving Technology : | EEE Compliant|RoHS 6 Compliant |
| 19" Rack Mountable : | Yes |
| Fans : | 3 |
| Dimensions (Size) : | 441 x 250 x 44 mm |
| Web-based GUI : | Yes |
| Layer : | Layer 3 |
| 10 Gig ports : | Yes |
| SFP+ ports : | 28 |
| Guest VLAN : | Yes |
| Layer 3 Switching : | Yes |
| IP Interfaces : | Yes |
| Routing Table Size : | 12K |
| Redundant PSU : | Yes |
| Stacking : | Physical and Virtual |
| Stacking Capacity : | Physical (9), Virtual (32) |
| Switch Type : | Layer 3 |
| Type of Port Required : | 10 Gigabit Fibre|25 Gigabit SFP28 |
| IGMP Snooping : | Yes |
| Number of Ports : | 24 - 32 |
| Stacking Bandwidth : | 200 Gbps |
| Redundant Power Supply : | Yes |
| Command Line Interface : | Yes |
| Switch Series : | DXS-3600 Series |
| 802.1X Access Control : | Yes |
